TSMC N3E와 삼성파운드리 3GAE의 비교 #Comparison between TSMC N3E and Samsung 3GAEIT_TECH 2023. 2. 28. 15:00
Q
TSMC N3E와 삼성파운드리 3GAE의 비교해줘
A
(N3E에 대한 자료가 부족함)
1)
TSMC의 N3E는 N3(3nm급) 공정의 개선 버전으로, 10~15% 향상된 성능, 25~30% 전력 절감,
최대 1.7배 향상된 트랜지스터 밀도[1] 등 N5에 비해 노드가 완전히 개선될 것으로 예상됩니다.
TSMC는 삼성 파운드리가 3GAE(3나노급, 게이트 일체형 공정)[2]를 사용하여 대량 생산을 시작한 지 몇 달 후에
N3 공정에 기반한 칩을 양산하기 시작했습니다.
TSMC가 공개한 N3의 공정 특성은 삼성이 공개한 3GAE의 특성과 비슷할 것으로 예상되며,
TSMC는 트랜지스터 밀도는 높지만 성능과 전력 효율은 낮습니다[3].
따라서 현재로서는 TSMC N3E와 삼성 3GAE의 비교가 명확하지 않습니다.
Translated with DeepL
2)
TSMC의 N3E는 N3(3nm급) 공정의 개선된 버전으로, N5에 비해 10%~15% 향상된 성능, 25%~30% 전력 감소, 최대 1.7배의 노드 개선을 가져올 것으로 예상됩니다. 트랜지스터 밀도 향상[1].
TSMC는 Samsung Foundry가 3GAE(3nm급 게이트 올 어라운드 공정)를 사용하여 대량 생산을 시작한 지
몇 달 후에 N3 공정을 기반으로 칩을 대량 생산하기 시작했습니다[2].
TSMC가 N3에 대해 공개한 프로세스 특성은 3GAE에 대한 삼성의 공개와 밀접하게 추적될 것으로 예상되며,
TSMC는 트랜지스터 밀도는 더 높지만 성능과 전력 효율은 더 낮습니다[3].
따라서 TSMC N3E와 Samsung 3GAE 간의 비교는 사용 가능한 소스에서 명확하지 않습니다.
Translated with Google
레퍼런스 (WebChatGPT)
[1] "N3E: An Improved 3nm Node Pulled In (Almost) TSMCs N3 is set to bring in full node improvements over N5, which includes 10% ~ 15% more performance, 25% ~ 30% power reduction, and an up to 1.7X ..." URL: https://www.anandtech.com/show/17356/tsmc-roadmap-update-n3e-in-2024-n2-in-2026-major-changes-incoming
TSMC Roadmap Update: N3E in 2024, N2 in 2026, Major Changes Incoming
Taiwan Semiconductor Manufacturing Co. has solid plans for the next few years, but the foundry's manufacturing technology design cycles are getting longer. As a result, to address all of its clients' needs, the company will have to keep offering half-nodes
www.anandtech.com
[2] "TSMC began mass production of chips based on its first N3 (3nm-class) fabrication process several months after Samsung Foundry kicked off high-volume manufacturing using its 3GAE (3nm-class, gate ..." URL: https://www.tomshardware.com/news/analysts-estimate-tsmc-n3-yields-between-60-and-80-percent
Analysts Estimate TSMC's 3nm Yields Between 60% and 80%
There are thousands of ways to improve yields.
www.tomshardware.com
[3] "N3 is planned to enter risk production in 2021 and enter volume production in 2H22. TSMCs disclosed process characteristics on N3 would track closely with Samsungs disclosures on 3GAE in ..." URL: https://www.anandtech.com/show/16024/tsmc-details-3nm-process-technology-details-full-node-scaling-for-2h22
TSMC Details 3nm Process Technology: Full Node Scaling for 2H22 Volume Production
At TSMC’s annual Technology Symposium, the Taiwanese semiconductor manufacturer detailed characteristics of its future 3nm process node as well as laying out a roadmap for 5nm successors in the form of N5P and N4 process nodes. Starting off with TSMC’s
www.anandtech.com
더보기TSMC's N3E is an improved version of its N3 (3nm-class) process, which is expected to bring in full node improvements over N5, including 10% to 15% more performance, 25% to 30% power reduction, and up to 1.7X improvement in transistor density [1]. TSMC began mass production of chips based on its N3 process several months after Samsung Foundry started high-volume manufacturing using its 3GAE (3nm-class, gate-all-around process) [2]. TSMC's disclosed process characteristics on N3 are expected to track closely with Samsung's disclosures on 3GAE, with TSMC having higher transistor density but lower performance and power efficiency [3]. Therefore, the comparison between TSMC N3E and Samsung 3GAE is not clear from the available sources.
